Especificaciones:
General
Interfaces
• 802.11b/g/n 2.4 GHz wireless
• 802.11ac/a/n 5 GHz wireless
• 10/100/1000BASE-T LAN (PoE) port
Antenna
• 4 x detachable external dual-band omnidirectional antennas
• 4 dBi for 5 GHz, 3 dBi for 2.4 GHz
Functionality
Operating Frequency
• 2400 to 2483.5 MHz
• 5150 to 5850 MHz
Operating Channels
• 1 to 13 channels for 2.4 GHz band (per country code)
• 36 to 165 channels for 5 GHz band (per country code)
System Management
• Web-based user interface (HTTP/HTTPs)
• Serial console (RJ-45)
• SNMP (v1/v2c/v3)
• Telnet/SSH
Security
SSID Security
• Up to 32 SSIDs, 16 per radio
• 802.1Q VLAN
• Station Isolation
Wireless Security
• WPA Personal/Enterprise
• AES and TKIP
Detection & Prevention
• Rogue and valid AP classification
Authentication
• MAC address filtering
Physical
Dimensions
• 205 x 39 mm (8.07 x 1.54 in.)
Weight
• 0.476 kg (1.05 lbs)
Power Supply
• 12 V/1.5 A external power adapter
• 802.3af PoE
Max Power Consumption
• 10.2 watts
Enclosure
• Bottom cover – plastic
• Top cover – plastic
• UL2043 certified chassis
Temperature
• Operating: 0 to 40 °C (32 to 104 °F)
• Storage: -20 to 65 °C (-4 to 149 °F)
Humidity
• Operating: 10% to 90% non-condensing
• Storage: 5% to 95% non-condensing
Certifications
• CE
• FCC
• IC
• cUL+UL
• LVD
• RCM
• NCC
• BSMI
• UL2043
