CARACTERÍSTICAS DE HARDWARE
Interfaz     " 8× 10/100/1000Mbps PoE+ RJ45 Ports (Auto-Negotiation/Auto MDI/MDIX)
" 2× 100/1000 Mbps SFP Slots
Cantidad de Ventiladores     Fanless
Bloqueo de Seguridad Físico
Fuente de Alimentación     External Power Adapter (Output: 53.5VDC/1.31A)
Puertos PoE (RJ45)     " Standard: 802.3af/at compliant
" PoE Ports: 8 Ports
" Power Supply: 61 W*
Dimensiones     8.2×4.9×1.0 in (209×126×26 mm)
Montaje     Desktop / Wall-Mounting
Consumo de Potencia Máximo     77.8 W (110 V/60 Hz) (with 61 W PD connected)
Disipación máxima de calor     265.3 BTU/hr (110 V/60 Hz) (with 61 W PD connected)
RENDIMIENTO
Capacidad de Conmutación     20 Gbps
Tasa de Reenvío de Paquetes     14.88 Mpps
Tabla de Direcciones MAC     8K
Memoria del Buffer de Paquete     4.1 Mbit
Jumbo Frame     9 KB
CARACTERÍSTICAS DE SOFTWARE
Calidad de Servicio     " 802.1p CoS/DSCP priority
" 8 priority queues
" Priority Schedule Mode
- SP (Strict Priority)
- WRR (Weighted Round Robin)
" Queue Weight Config
" Bandwidth Control
- Port/Flow based Rating Limit
" Smoother Performance
" Storm Control
- Multiple Control Modes(kbps/ratio)
- Broadcast/Multicast/Unknown-Unicast Control
Características L2 y L2+     " 32 IP Interfaces: Support IPv4/IPv6 Interface
" Static Routing: 32 IPv4/IPv6 Static Routes
" DHCP Server
" DHCP Relay
- DHCP Interface Relay
- DHCP VLAN Relay
" DHCP L2 Relay
" Static ARP
" Proxy ARP
" Gratuitous ARP
" Link Aggregation
" Spanning Tree Protocol
" Loopback Detection
" 802.3x Flow Control
" Mirroring
" Device Link Detect Protocol (DLDP)
" 802.1ab LLDP/ LLDP-MED
Multicast L2     " 511 IPv4, IPv6 shared multicast groups
" IGMP Snooping
" Multicast VLAN Registration (MVR)
" Multicast Filtering
" Limited IP Multicast (256 profiles and 16 entries per profile)
Características Avanzadas     " Automatic Device Discovery
" Batch Configuration
" Batch Firmware Upgrading
" Intelligent Network Monitoring
" Abnormal Event Warnings
" Unified Configuration
" Reboot Schedule
VLAN     " VLAN Group
- Max. 4K VLAN Groups
" 802.1Q tag VLAN
" MAC VLAN: 12 Entries
" Protocol VLAN
" GVRP
" Voice VLAN
Lista de Control de Acceso     " Support up to 230 entries
" Time-based ACL
" MAC ACL
" IP ACL
" IPv6 ACL
" Combined ACL
" Rule Operation: Permit/Deny
" Policy Action
- Mirroring
- Redirect
- Rate Limit
- QoS Remark
" ACL Rules Binding
- Port Binding
- VLAN Binding
Seguridad     " IP-MAC-Port Binding
" AAA
" 802.1X
- Port-based authentication
- MAC (Host) based authentication
- Authentication Method includes PAP/EAP-MD5
- MAB
- Guest VLAN
- Support Radius authentication and accountability
" IP/IPv6-MAC Binding
- 512 Binding Entries
- DHCP Snooping
- DHCPv6 Snooping
- ARP Inspection
- ND Detection
" IP Source Guard
- 253 Entries
- Source IP+Source MAC
" IPv6 Source Guard
- 183 Entries
- Source IPv6 Address+Source MAC
" DoS Defend
" Static/Dynamic/Permanent Port Security
- Up to 64 MAC addresses per port
" Broadcast/Multicast/Unicast Storm Control
- kbps/ratio control mode
" Port Isolation
" Secure web management through HTTPS with SSLv3/TLS 1.2
" Secure Command Line Interface (CLI) management with SSHv1/SSHv2
" IP/Port/MAC-based access control
IPv6     " IPv6 Static Routing and ACL
" IPv6 Dual IPv4/IPv6
" IPv6 Interface
" Multicast Listener Discovery (MLD) Snooping
" IPv6 neighbor discovery (ND)
" Path maximum transmission unit (MTU) discovery
" Internet Control Message Protocol (ICMP) version 6
" TCPv6/UDPv6
" IPv6 applications
- DHCPv6 Client
- Ping6
- Tracert6
- Telnet(v6)
- IPv6 SNMP
- IPv6 SSH
- IPv6 SSL
- Http/Https
- IPv6 TFTP
MIBs     " MIB II (RFC1213)
" Bridge MIB (RFC1493)
" P/Q-Bridge MIB (RFC2674)
" Radius Accounting Client MIB (RFC2620)
" Radius Authentication Client MIB (RFC2618)
" Remote Ping, Traceroute MIB (RFC2925)
" Support TP-Link private MIBs
" RMON MIB(RFC1757, rmon 1,2,3,9)
GESTIÓN
Omada App     Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Gestión Centralizada     " Omada Cloud-Based Controller
" Omada Hardware Controller
" Omada Software Controller
Acceso a la nube     Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Aprovisionamiento sin contacto     Yes. Requiring the use of Omada Cloud-Based Controller
Funciones de gestión     " Web-based GUI
" Command Line Interface (CLI) through telnet
" SNMPv1/v2c/v3
" SNMP Trap/Inform
" RMON (1,2,3,9 groups)
" SDM Template
" DHCP/BOOTP Client
" Dual Image, Dual Configuration
" CPU Monitoring
" Cable Diagnostics
" EEE
" SNTP
" System Log
Otros
Certificaciones     CE, FCC, RoHS
Contenido del Paquete     " SG2210P
" Power Adapter
" Installation Guide
" Rubber Feet
Requisitos del sistema     Microsoft® Windows® 98SE, NT, 2000, XP, Vista" or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.
Factores Ambientales     " Operating Temperature: 0~40 (32 ~104 );
" Storage Temperature: -40~70 (-40 ~158 )
" Operating Humidity: 10%~90% non-condensing
" Storage Humidity: 5%~90% non-condensing
